ZNC600 ZNC EDM Sparking Machine

ZNC600 ZNC EDM Sparking Machine


ZNC die sinking EDM has X and Y axis manual control and Z axis program control, with handwheel of X and Y axis, it is fast and convenient to locate position for spark discharge machining. Due to affordable cost and good performance, ZNC EDM is widely used in producing various plastic injection molds, such as home applications, electronic connectors, powder metallurgy, automotive molds, and other industries.


Main Dimensions of ZNC600 ZNC EDM Sparking Machine

X×Y×Z travel:600×500×220mm;

Working table dimension:900×500mm;

Working tank on the table: 1320×800×500mm


ZNC600 ZNC EDM Sparking Machine Specifications


Items

unit

ZNC600

Oil load capacity of the table

mm

1320×800×500

Table size

mm

900×500

Travel of X/Y/Z

mm

600×500×220

2nd Z axis travel

mm

260

Distance from spindle end to the table

mm

340-800

Oil tank dimension

mm

1100×1900×510

Max load of electrode weight

Kg

50

Load of table

Kg

1000

Dimension of machine

mm

2500×1900×2350

Net weight of the machine

Kg

2100


Outline Drawing


ZNC600 ZNC EDM Sparking Machine Layout
ZNC600 ZNC EDM Sparking Machine Layout
ZNC600 ZNC EDM Sparking Machine Layout
ZNC600 ZNC EDM Sparking Machine Layout
