- Precision & Finish: Cylindricity ≤0.008mm at 100mm thickness; best Ra0.6 after 1 rough and 3 trim cuts.
- For Cutting workpeice with height: 40–100 mm.
Cutting Speed (6 A):
- Single-cut: 10,000 mm²/h
- One-cut, one-trim: 6,500 mm²/h
- One-cut, two-trims: 5,500 mm²/h
- Control System: Windows-based intelligent system with a complete cutting parameters database (easy to learn with 2 hours of beginner training).
- Components & Mechanics: Imported Taiwan linear guideway and Delta AC servo motors; UV axes with precision linear guideways and ball screws; standard with ±15° taper cutting system.
- Operation: Wire-loading damper to prevent manual threading and wire overlap.
- Design & Power: "C" structure column and high rigidity machine body with abundant reinforcing ribs to maintain long-term accuracy. Space-saving integrated electric cabinet with high-quality electronic components, delivering up to 10 A maximum machining current.
Main Dimensions of A550 CNC Wire Cut EDM Machine C Structure
X×Y×Z travel: 550×450×300mm;
Working table dimension: 730×550mm;
Weight of the machine: 1900kg
Load of the table: 500kg
Wire drum type: fixed
Wire Reuse via circulation
All relevant CAM software and post-processor be provided with the machine
A550 CNC Wire Cut EDM Machine C Structure Specifications
Name | A550 |
X×Y×Z travel | 550×450×300mm |
| U, V travel | 100 x100 mm |
Working table dimension | 730×550mm |
Max cut angle/thickness | ±15°/80mm |
| Cut Accuracy(Straight/Taper): | +0.005/+0.015(Cr12,H=20mm, octagonal bar,L12mm) |
Max load of the working table | 500kg |
Surface finish | Ra ≤ 0.8 m(Cr12,H=60mm) |
Max cutting speed | ≥200mm2/min |
Min drive unit | 0.001mm |
The diameter of the electrode wire | Φ0.12-Φ0.25mm |
Weight of machine | 1900kg |
Dimension of machine | 1900×1600×2100mm |
Max cutting current | 10A |
Power supply | 3 phase 380V/50Hz |
Rated power | ≤1.5KVA |
Working tank |
Capacity of tank | 100L |
Filtration | Ultrafine filtration |
Dimension of tank | 1000×500×700mm |
Weight of tank | 80/60kg |
Outline Drawing
