The 60pro is Dimeng’s flagship CNC EDM for large‑size precision mold processing. Adopting high‑rigidity cast‑iron bed and self‑developed discharge power system, it achieves excellent mirror‑surface effect with low electrode wear. Optional C‑axis and electrode tool magazine support automatic unmanned production, widely used for large molds, automotive and aerospace components.
Main Dimensions of A45 CNC Die Sinking EDM Machine
X×Y×Z travel: 600×400×350mm;
Working table dimension: 600×400mm;
Working tank on the table: 1090×630×445mm
A45 CNC Die Sinking EDM Machine Specifications
No. | Name | A45 |
1 | Working table dimension(L×W) | 600×400mm |
2 | X, Y, Z axis travel | 452×300×272mm |
3 | Working tank dimension(L×W×H） | 1090×630×445mm |
4 | Highest level of working liquid | 290mm |
5 | End of the spindle to the working table | 600mm |
6 | Capacity of the oil tank | 600L |
7 | Max weight of the electrode | 25kg |
8 | Max weight of the workpiece | 400kg |
9 | Positioning accuracy | 6µm |
10 | Repeat positioning accuracy | 3.5µm |
11 | Weight of machine | 3100kg |
12 | Dimension of machine | 1500×1680×2350mm |
13 | General input | 9kVA(50A) |
14 | Input power | 3 Phase 220/60Hz |
15 | CNC power generator | A3-50 |
16 | Max working current | 50A |
17 | Best surface finish | Ra≤0.08µm |
18 | Min. wear of the electrode | ≤0.05% |
19 | Max machining efficiency | ≥500mm3/min |
20 | Interpolation methods | Straight line, arc, helix |
21 | Accuracy compensation options | Step pitch compensation of each axis, gap compensation |
22 | Min. drive unit | 1µm |
23 | The outer dimension of the controller | 1250×550×1800mm |
24 | Display | 15-inch touch screen |
25 | Remote control | different gradesMFR0-3 |
Outline Drawing
Product Specifications
No. | Name | A45 |
1 | Working table dimension(L×W) | 600×400mm |
2 | X, Y, Z-axis travel | 452×300×272mm |
3 | Working tank dimension(L×W×H） | 1090×630×445mm |
4 | Highest level of working liquid | 290mm |
5 | End of the spindle to the working table | 600mm |
6 | The capacity of the oil tank | 600L |
7 | Max weight of the electrode | 25kg |
8 | Max weight of the workpiece | 400kg |
9 | Positioning accuracy | 6µm |
10 | Repeat positioning accuracy | 3.5µm |
11 | Weight of machine | 3100kg |
12 | Dimension of machine | 1500×1680×2350mm |
13 | General input | 9kVA(50A) |
14 | Input power | 3 Phase 220/60Hz |
15 | CNC power generator | A3-50 |
16 | Max working current | 50A |
17 | Best surface finish | Ra≤0.08µm |
18 | Min. wear of the electrode | ≤0.05% |
19 | Max machining efficiency | ≥500mm3/min |
20 | Interpolation methods | Straight line, arc, helix |
21 | Accuracy compensation options | Step pitch compensation of each axis, gap compensation |
22 | Min. drive unit | 1µm |
23 | The outer dimension of the controller | 1250×550×1800mm |
24 | Display | 15-inch touch screen |
25 | Remote control | different gradesMFR0-3 |
